PART NO. | PITCH | NO. OF CONTACTS | PRODUCT DESCRIPTION | COLOR OF COVER |
254DS-xxxG* | 2.54mm | 001~010, 012 | Slide type with raised actuator | BK, RD, BL |
254DR-xxxG* | 2.54mm | 001~010, 012 | Slide type with recessed actuator | ditto |
254DP-xxxG* | 2.54mm | 002~010, 012 | Piano type with short key | ditto |
254DQ-xxxG* | 2.54mm | 002~010, 012 | Piano type with long key | ditto |
254DL-xxxG* | 2.54mm | 001~010, 012 | Right angle type with raised actuator | ditto |
254DH-xxxGB | 2.54mm | 001~010, 012 | Machine insertable type (Automatic Assembly) with raised actuator & splay terminal | black |
254DJ-xxxGB | 2.54mm | 001~010, 012 | Machine insertable type (Manual Assembly) with raised actuator & straight terminal | black |
254DK-xxxGB | 2.54mm | 001~010, 012 | Machine insertable type (Automatic Assembly) with recessed actuator & splay terminal | black |
254DT-xxxGB | 2.54mm | 001~010, 012 | Machine insertable type (Manual Assembly) with recessed actuator & straight terminal | black |
254DF-xxxGB-T(-R) | 2.54mm | 001~010, 012 | SMT type with raised actuator | black |
254DG-xxxGB-R | 2.54mm | 001~010, 012 | SMT type with recessed actuator | black |
127DG-xxxGB-R | 1.27mm | 002~010 | 1.6mm low profile SMT type H=6.7mm | black |
127DH-xxxGB-R | 1.27mm | 002~010 | 1.6mm low profile SMT type H=8.1mm | black |
127DK-xxxGB-R | 1.27mm | 002~010 | 2.2mm low profile SMT type H=8.1mm | black |
